CTCSS/DCS Encode and Decode Network Customizable 10W Full Duplex Walkie Talkie Repeater

CTCSS/DCS Encode and Decode Network Customizable 10W Full Duplex Walkie Talkie Repeater

Product Details:

Place of Origin: China
Brand Name: OEM
Model Number: V9

Payment & Shipping Terms:

Price: $325.00/pieces 1-4 pieces
Payment Terms: T/T, L/C, MoneyGram, PayPal, Western Union
Get Best Price Contact Now

Detail Information
Type: Walkie Talkie Repeater Network: CTCSS/DCS Encode And Decode

Product Description









CTCSS/DCS Encode and Decode Network Customizable 10W Full Duplex Walkie Talkie Repeater 0CTCSS/DCS Encode and Decode Network Customizable 10W Full Duplex Walkie Talkie Repeater 1CTCSS/DCS Encode and Decode Network Customizable 10W Full Duplex Walkie Talkie Repeater 2CTCSS/DCS Encode and Decode Network Customizable 10W Full Duplex Walkie Talkie Repeater 3CTCSS/DCS Encode and Decode Network Customizable 10W Full Duplex Walkie Talkie Repeater 4CTCSS/DCS Encode and Decode Network Customizable 10W Full Duplex Walkie Talkie Repeater 5CTCSS/DCS Encode and Decode Network Customizable 10W Full Duplex Walkie Talkie Repeater 6





Frequency
UHF:TX 463.3125MHz / RX 453.3125MHz
VHF:TX 162.6125MHz / RX 152.6125MHz
Customize:136-174MHz/400-470MHz
Note: Transmit and receive frequencies to be customized
Channel Capacity
16CH
Channel Spacing
±12.5KHz Narrow/±25KHz Wide
Operating Temperature
-30℃~+60℃
Operating Voltage
DC12V-24V
Antenna Impedance
50Ω
Frequency Stability
±0.5ppm
Dimension
280×210×75mm
Weight
2624g
Transmitter
Output power
10W
Transmission Current
≤2.5A
FM Modulation
11kφF3E/16kφF3E
Digital modulation
4FSK
Modulation Distortion
≤5%
FM Noise
≥40dB(25KHz)/≥35dB(12.5KHz)
Adjacent Channel Power
≥70dB(25KHz)/≥60dB(12.5KHz)
Audio Response
+1~-3dB
DMR Protocol
ETSI-TS102 361-1,-2,-3
Receiver
Analog receive Sensitivity
0.25μν(12dB)SINAD
Digital receive sensitivity
-120dBm (BER≤5%)
Adjacent channel selectivity
≥70dB(25KHz)/≥60dB(12.5KHz)
Inter-modulation
≥60dB/≥65dB
Signal imitation
≥70dB
Audio Response
+1~-3dB
Audio distortion
<5%
FM Noise
≥45dB(25KHz)/≥40dB(12.5KHz)
